|DC 输出||24 - 28Vdc|
|20 - 17A|
|输入||AC 100 - 240V (± 15%)|
|DC 110V - 150V (-20%/+25%)|
|尺寸（宽x高x深）||82 x 124 x 127mm|
|AC输入电压||AC 100 - 240V (± 15%)|
|DC输入电压||DC 110V - 150V (-20%/+25%)|
|输入浪涌电流||9A / 7A|
|外部输入保险丝推荐||B-10A / C-10A|
|调压范围||24 - 28V|
|输出电流范围||20 - 17A|
|输出电流||17A 当 28V|
|20A 当 24V|
|降额||12W/°C 为 >+60°C|
|尺寸（宽x高x深）||82mm x 124mm x 127mm|
|Weight per unit (excl. packaging)||1200g|
|工作温度范围||-25°C 至 70°C|
|平均无故障时间 SN 29500 @ 40°C (h)||469000h|
