24V, 12.5A 输入：HanQ4/2 | 输出：HanQ4/0
|DC 输出||24 - 24Vdc|
|12.5 - 12.5A|
|输入||AC 380 - 480V (± 15%)|
|尺寸（宽x高x深）||182 x 183 x 59mm|
|AC输入电压||AC 380 - 480V (± 15%)|
|外部输入保险丝推荐||B-6A / C-6A|
|调压范围||24 - 24V|
|输出电流范围||12.5 - 12.5A|
|输出电流||12.5A 当 24V|
|12.5A 当 24V|
|功率储备||50% (up to 60s)|
|降额||10W/°C 为 +55 to +70°C|
|尺寸（宽x高x深）||182mm x 183mm x 59mm|
|Weight per unit (excl. packaging)||1200g|
|工作温度范围||-25°C 至 70°C|
|连接端子类型||Input: HanQ4/2 | Output: HanQ4/0|
|平均无故障时间 SN 29500 @ 40°C (h)||814000h|
