12V, 16A 增强型直流输入
|DC 输出||12 - 15Vdc|
|16 - 12.8A|
|输入||AC 100 - 240V (-15%/+10%)|
|DC 110V - 300V (± 20%)|
|尺寸（宽x高x深）||39 x 124 x 117mm|
|AC输入电压||AC 100 - 240V (-15%/+10%)|
|DC输入电压||DC 110V - 300V (± 20%)|
|输入浪涌电流||6A / 9A|
|外部输入保险丝推荐||B-6A / C-6A|
|调压范围||12 - 15V|
|输出电流范围||16 - 12.8A|
|输出电流||12.8A 当 15V|
|16A 当 12V|
|降额||4.8W/°C 为 >60°C|
|尺寸（宽x高x深）||39mm x 124mm x 117mm|
|Weight per unit (excl. packaging)||600g|
|工作温度范围||-25°C 至 70°C|
|平均无故障时间 SN 29500 @ 40°C (h)||690000h|
